Measurement and Validation

Digital Calipers / Micrometres:
  • Manufacturer: Mitutoyo/Moore and Wright
  • Capacity: Up to 1000mm
  • Measurements: Bores, grooves, wall thickness and recesses are checked with ease
Manual Calipers / Micrometres:
  • Manufacturer: Mitutoyo/Moore and Wright
  • Capacity: Up to 1400mm
  • Measurements: Bores, grooves, wall thickness and recesses are checked with ease
Manual CMM:
  • Manufacturer: Mitutoyo
  • Capacity: X1500 x Y600 x Z800mm
  • Measurements: angles, diameters, centres, cones, spheres and intersection points, concentricity, squareness with dimensional printouts
  • Accuracy: 0.008mm
FARO Arm:
  • Manufacturer: FARO
  • Capacity: 2.7m (9) – Seven axes
  • Measurements: Portable measurement arm. Cartesian, polar coordinates – angles, intersection points
  • Accuracy: Single point 0.029, volumetric +/-0.04
Various Thread Plug Gauges:
  • NPT,API,BSP,BSPT,BSPF,UNC,UNF,METRIC
Digital Co-ordinate Height Gauge:
  • Manufacturer: Mitutoyo
  • Capacity: upto1000MM
  • Measurements: Diameters – point-to-point dimensions depths using different types of styles
  • Accuracy: +/- 0.010mm
Ultrasonic Thickness Gauge:
  • Manufacturer: Sauter
  • Capacity: 0.75-80mm
  • Measurements: Wall thickness
CMM:
  • Manufacturer: ITP
  • Capacity: 300 x 300 x 400mm – three axes
  • Measurements: Cartesian / Polar co-ordinates – angles, diameters, centres, cones, spheres and intersection points with dimensional printouts
  • Accuracy: +/- 0.015mm
Digital Co-ordinate Height Gauge:
  • Manufacturer: Trimos
  • Capacity: 2400mm – two axes
  • Measurements: Diameters – point-to-point dimensions depths using different types of styles
  • Accuracy: +/- 0.010mm
FARO Arm:
  • Manufacturer: FARO
  • Capacity: 1200mm – three axes
  • Measurements: Portable measurement arm. Cartesian, polar coordinates – angles, intersection points
  • Accuracy: ±0.00015mm
Digital Shadow Graph:
  • Manufacturer: Batty R14 – digital
  • Capacity: 150mm dia.
  • Measurements: Non-contact measurement. Geometric function for skew alignment – circles, lines, angles, radius and chamfer measurement.
Bower Digital Bore Micrometres:
  • Manufacturer: Mitutoyo
  • Capacity: 20mm – 150mm
  • Measurements: Electronic measuring scales provide direct readout of mainly bores – checks any ovality and roundness
  • Accuracy: ± 0.0005mm
Digital Tele Surf:
  • Manufacturer: Mitutoyo
  • Measurements: Surface roughness measurements – In Ra, Rq and Rz. Prints measurements with customer, part number, batch number for traceability.
Digital Calipers / Micrometres:
  • Manufacturer: Mitutoyo
  • Capacity: Up to 800mm
  • Measurements: Bores, grooves, wall thickness and recesses are checked with ease
Haas Machining Centre Automatic Probing:
  • Machining centres with wireless intuitive probing system (WIPS) which enables precision measurements of components while still in the machine.
